Postgres Auditing in 150 lines of SQL

2022-03-08

13 minute read

Data auditing is a system that tracks changes to tables' contents over time. PostgreSQL has a robust set of features which we can leverage to create a generic auditing solution in 150 lines of SQL.

Auditing is particularly useful for historical analysis. To demonstrate, imagine you have a users table that tracks when a user is online. You might add a status column which can have one of two values: online and offline. How would you track how long a user is online for throughout an entire month? An auditing system would track every change with timestamps, and so you can measure the difference between each timestamp and sum them up for the entire month.

The goals of our auditing solution are:

  • low maintenance
  • easy to use
  • fast to query

To demonstrate what we're working towards, the following example shows what we'll have at the end of the blog post:


_10
-- create a table
_10
create table public.members (
_10
id int primary key,
_10
name text not null
_10
);
_10
_10
-- Enable auditing on the new table
_10
select audit.enable_tracking('public.members');

Produce some records to audit


_13
-- create a new record
_13
insert into public.members
_13
(id, name)
_13
values
_13
(1, 'foo');
_13
_13
-- edit the record
_13
update public.members
_13
set name = 'bar'
_13
where id = 1;
_13
_13
-- delete the record
_13
delete from public.members;

Review the audit log


_10
select * from audit.record_history;


_10
id | record_id | old_record_id | op | ts | table_oid | table_schema | table_name | record | old_record
_10
----+--------------------------------------+--------------------------------------+--------+-------------------------------------+-----------+--------------+------------+--------------------------+--------------------------
_10
2 | 1ecd5ff0-1b6b-5bc2-ad80-1cb19769c081 | | INSERT | Mon Feb 28 18:13:52.698511 2022 PST | 16452 | public | members | {"id": 1, "name": "foo"} |
_10
3 | 1ecd5ff0-1b6b-5bc2-ad80-1cb19769c081 | 1ecd5ff0-1b6b-5bc2-ad80-1cb19769c081 | UPDATE | Mon Feb 28 18:13:52.698511 2022 PST | 16452 | public | members | {"id": 1, "name": "bar"} | {"id": 1, "name": "foo"}
_10
4 | | 1ecd5ff0-1b6b-5bc2-ad80-1cb19769c081 | DELETE | Mon Feb 28 18:13:52.698511 2022 PST | 16452 | public | members | | {"id": 1, "name": "bar"}
_10
(3 rows)

Notice that our record_id and old_record_id stayed constant as we updated the row so we can easily query for a single row's history over time!

Lets get building

Namespace

To quote a tenet from the zen of python:

Namespaces are one honking great idea -- let's do more of those!

So first things first, we'll create a separate schema named audit to house our auditing entities.


_10
create schema if not exists audit;

Storage

Next, we need a table to track inserts, updates and deletes.

Classically, an audit table's schema mirrors the table being audited and appends some metadata columns like the commit's timestamp. That solution has a few maintenance challenges:

  • enabling auditing on a table requires a database migration
  • when the source table's schema changes, the audit table's schema must also change

So instead, we'll lean on PostgreSQL's schema-less JSONB data type to store each record's data in a single column. That approach has the added benefit of allowing us to store multiple tables' audit history in a single audit table.


_15
create table audit.record_version (
_15
id bigserial primary key,
_15
-- auditing metadata
_15
record_id uuid, -- identifies a new record by it's table + primary key
_15
old_record_id uuid, -- ^
_15
op varchar(8) not null, -- INSERT/UPDATE/DELETE/TRUNCATE
_15
ts timestamptz not null default now(),
_15
-- table identifiers
_15
table_oid oid not null, -- pg internal id for a table
_15
table_schema name not null, -- audited table's schema name e.g. 'public'
_15
table_name name not null, -- audited table's table name e.g. 'account'
_15
-- record data
_15
record jsonb, -- contents of the new record
_15
old_record jsonb -- previous record contents (for UPDATE/DELETE)
_15
);

Postgres version compatibility

The table above uses PostgreSQL's built-in uuid functionality, which is available from version 14. For backwards compatibility you can use the uuid-ossp extension.

create extension if not exists "uuid-ossp";

Query Patterns

An audit log doesn't do us much good if its too slow to query! There are 2 query patterns we think are table stakes (😉) for an audit system:

Changes to a Table in a Time Range

For time slices, we need an index on the ts column. Since the table is append-only and the ts column is populated by insertion date, our values for ts are naturally in ascending order.

PostgreSQL's builtin BRIN index can leverage that correlation between value and physical location to produce an index that, at scale, is many hundreds of times smaller than the default (BTREE index) with faster lookup times.


_10
-- index ts for time range filtering
_10
create index record_version_ts
_10
on audit.record_version
_10
using brin(ts);

For table filtering, we've included a table_oid column which tracks PostgreSQL's internal numeric table identifier. We can add an index to this column instead of the table_schema and table_name columns, minimizing the index size and offering better performance.


_10
-- index table_oid for table filtering
_10
create index record_version_table_oid
_10
on audit.record_version
_10
using btree(table_oid);

Changes to a Record Over Time

One of the downsides to storing each row's data as jsonb is that filtering based on a column's value becomes very inefficient. If we want to look up a row's history quickly, we need to extract and index a unique identifier for each row.

For the globally unique identifier, we'll use the following structure


_10
[table_oid, primary_key_value_1, primary_key_value_2, ...]

and hash that array as a UUID v5 to get an efficiently indexable UUID type to identify the row that is robust to data changes.

We'll use one utility function to lookup a record's primary key column names:


_21
create or replace function audit.primary_key_columns(entity_oid oid)
_21
returns text[]
_21
stable
_21
security definer
_21
language sql
_21
as $$
_21
-- Looks up the names of a table's primary key columns
_21
select
_21
coalesce(
_21
array_agg(pa.attname::text order by pa.attnum),
_21
array[]::text[]
_21
) column_names
_21
from
_21
pg_index pi
_21
join pg_attribute pa
_21
on pi.indrelid = pa.attrelid
_21
and pa.attnum = any(pi.indkey)
_21
where
_21
indrelid = $1
_21
and indisprimary
_21
$$;

and another to consume the table_oid and primary key, converting the result into the record's UUID.


_28
create or replace function audit.to_record_id(
_28
entity_oid oid,
_28
pkey_cols text[],
_28
rec jsonb
_28
)
_28
returns uuid
_28
stable
_28
language sql
_28
as $$
_28
select
_28
case
_28
when rec is null then null
_28
-- if no primary key exists, use a random uuid
_28
when pkey_cols = array[]::text[] then gen_random_uuid()
_28
else (
_28
select
_28
uuid_generate_v5(
_28
'fd62bc3d-8d6e-43c2-919c-802ba3762271',
_28
(
_28
jsonb_build_array(to_jsonb($1))
_28
|| jsonb_agg($3 ->> key_)
_28
)::text
_28
)
_28
from
_28
unnest($2) x(key_)
_28
)
_28
end
_28
$$;

Finally, we index the record_id and old_record_id columns that contain these unique identifiers for fast querying.


_10
-- index record_id for fast searching
_10
create index record_version_record_id on audit.record_version (record_id)
_10
where record_id is not null;
_10
_10
-- index old_record_id for fast searching
_10
create index record_version_old_record_id on audit.record_version (record_id)
_10
where old_record_id is not null;

Enrollment

Okay, so we have a home for our audit data that we're confident it can be queried efficiently. Now how do we populate it?

We need the audit table to populate without end-users making any changes to their transactions. So we'll set up a trigger to fire when the data changes. In this case, we'll fire the trigger once for every inserted/updated/deleted row.


_36
create or replace function audit.insert_update_delete_trigger()
_36
returns trigger
_36
security definer
_36
language plpgsql
_36
as $$
_36
declare
_36
pkey_cols text[] = audit.primary_key_columns(TG_RELID);
_36
record_jsonb jsonb = to_jsonb(new);
_36
record_id uuid = audit.to_record_id(TG_RELID, pkey_cols, record_jsonb);
_36
old_record_jsonb jsonb = to_jsonb(old);
_36
old_record_id uuid = audit.to_record_id(TG_RELID, pkey_cols, old_record_jsonb);
_36
begin
_36
_36
insert into audit.record_version(
_36
record_id,
_36
old_record_id,
_36
op,
_36
table_oid,
_36
table_schema,
_36
table_name,
_36
record,
_36
old_record
_36
)
_36
select
_36
record_id,
_36
old_record_id,
_36
TG_OP,
_36
TG_RELID,
_36
TG_TABLE_SCHEMA,
_36
TG_TABLE_NAME,
_36
record_jsonb,
_36
old_record_jsonb;
_36
_36
return coalesce(new, old);
_36
end;
_36
$$;

Public API

Finally, we'll wrap up the trigger creation and removal process behind a clean, idempotent, user facing API.

The API we'll expose for enabling auditing on a table is


_10
select audit.enable_tracking('<schema>.<table>'::regclass);

and for disabling tracking


_10
select audit.disable_tracking('<schema>.<table>'::regclass);

Under the hood, those functions register our auditing trigger against the requested table.


_43
create or replace function audit.enable_tracking(regclass)
_43
returns void
_43
volatile
_43
security definer
_43
language plpgsql
_43
as $$
_43
declare
_43
statement_row text = format('
_43
create trigger audit_i_u_d
_43
before insert or update or delete
_43
on %I
_43
for each row
_43
execute procedure audit.insert_update_delete_trigger();',
_43
$1
_43
);
_43
_43
pkey_cols text[] = audit.primary_key_columns($1);
_43
begin
_43
if pkey_cols = array[]::text[] then
_43
raise exception 'Table % can not be audited because it has no primary key', $1;
_43
end if;
_43
_43
if not exists(select 1 from pg_trigger where tgrelid = $1 and tgname = 'audit_i_u_d') then
_43
execute statement_row;
_43
end if;
_43
end;
_43
$$;
_43
_43
create or replace function audit.disable_tracking(regclass)
_43
returns void
_43
volatile
_43
security definer
_43
language plpgsql
_43
as $$
_43
declare
_43
statement_row text = format(
_43
'drop trigger if exists audit_i_u_d on %I;',
_43
$1
_43
);
_43
begin
_43
execute statement_row;
_43
end;
_43
$$;

And we're done with 2 lines of code to spare!

Performance

Auditing tables always reduces throughput of inserts, updates, and deletes. In cases where throughput is less than 1000 writes per second the overhead is typically negligible. For tables with a higher write frequency, consider logging changes outside of SQL with a tool like pgAudit.

Do I really expect you to copy/paste all that?

Nope, for a turnkey solution to auditing in PostgreSQL, we've packaged this script into an extension with some extra goodies like TRUNCATE support. Check it out at https://github.com/supabase/supa_audit.
