How ChartDB works with Supabase

Once connected, ChartDB securely reads your Supabase Postgres schema and automatically generates an ER diagram with tables, columns, indexes, and relationships. Common use cases for Supabase users include:

• Visualizing complex schemas as projects grow
• Reviewing and planning schema changes before applying migrations
• Sharing a clear database overview with teammates or stakeholders
• Reducing onboarding time for new developers

Getting started

1. Connect your Supabase project using OAuth
2. Select the database you want to visualize
3. ChartDB automatically imports the schema and generates a diagram
4. Explore, group tables, annotate, and export or share the diagram No manual queries or exports required.
